SMC 3-way KQ2VT threaded angle fitting – 360° swivelling – brass/PBT – with face seal – hose Ø 4 to 12 mm – pack of 5 or 10 – price per piece

Product Description
  • The SMC KQ2VT threaded elbow is used to create a right-angled branch from a female thread.
  • Typical areas of application include industrial automation, assembly lines, production cells and general mechanical engineering.
  • The flexible design allows several consumers to be connected in parallel within compact system structures.
  • These are particularly useful for extensions or modifications where quick and neat plug-in connections are required.
Description
  • The swivelling, triple SMC KQ2VT threaded elbow consists of a brass and PBT body and robust POM pressure rings, and is fitted with a face seal.
  • The three angled connectors can be rotated independently of one another through 360°.
  • The compact design of the push-fit screw fitting allows it to be used even where space is limited.
  • The meticulous workmanship ensures permanently leak-proof connections, even when the hoses are frequently reconnected.
Technical Data
  • Housing material – C3604, PBT
  • Material: Metal body (threaded part) – C3604
  • Collet material – 304 stainless steel
  • Guide material – 304 stainless steel
  • Material of pressure ring – POM
  • Seal material, O-ring – NBR
  • Medium – Compressed air/water
  • Operating pressure range – –0.1 to 10 bar
  • Test pressure – 30 bar
  • Ambient and fluid temperature – –5 to 60 °C, water 0 to 40 °C (not frozen)
  • Suitable hose outer diameter – 4 to 12 mm
  • Connection thread – R 1/8" or 1/2"
  • Min. connection size – 3 to 9 mm
  • Spanner size – 14 to 27 mm
  • Length – 26.3 to 42.4 mm
  • Height – 53.8 to 89.5 mm
  • Weight – 27.5 to 158.6 g
  • Price per item
show more...
show less...
From € 15,58
Price incl. VAT
plus € 29,00 shipping costs
In 16 variations available
Please Choose Version...

Do you have any questions?
We would like to assist you!
verkauf@esska.de
Versions: (16)
Narrow down your selection
Hose outer diameter
Connection thread
Pack size
Part No.
Type
show all 16 implementations
Anzeigen als list Table
Item No.: 973011631410
Type
Hose outer diameter4 mm
Connection threadR 1/8"
Pack size10 pieces
Part No.-
TypeKQ2VT04-01AP
€ 15,58
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 4 weeks
Item No.: 973011631411
Type
Hose outer diameter4 mm
Connection threadR 1/4"
Pack size10 pieces
Part No.-
TypeKQ2VT04-02AP
€ 15,87
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Item No.: 973011631412
Type
Hose outer diameter4 mm
Connection threadR 3/8"
Pack size10 pieces
Part No.-
TypeKQ2VT04-03AP
€ 16,94
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 4 weeks
Item No.: 973011631413
Type
Hose outer diameter6 mm
Connection threadR 1/8"
Pack size10 pieces
Part No.-
TypeKQ2VT06-01AP
€ 15,78
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Item No.: 973011631414
Type
Hose outer diameter6 mm
Connection threadR 1/4"
Pack size10 pieces
Part No.-
TypeKQ2VT06-02AP
€ 16,17
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 4 weeks
Item No.: 973011631415
Type
Hose outer diameter6 mm
Connection threadR 3/8"
Pack size10 pieces
Part No.-
TypeKQ2VT06-03AP
€ 17,30
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 7-10 working days
Item No.: 973011631416
Type
Hose outer diameter8 mm
Connection threadR 1/8"
Pack size10 pieces
Part No.-
TypeKQ2VT08-01AP
€ 18,14
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Item No.: 973011631417
Type
Hose outer diameter8 mm
Connection threadR 1/4"
Pack size10 pieces
Part No.-
TypeKQ2VT08-02AP
€ 18,39
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Item No.: 973011631418
Type
Hose outer diameter8 mm
Connection threadR 3/8"
Pack size10 pieces
Part No.-
TypeKQ2VT08-03AP
€ 17,14
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 7-10 working days
Item No.: 973011631419
Type
Hose outer diameter8 mm
Connection threadR 1/2"
Pack size10 pieces
Part No.-
TypeKQ2VT08-04AP
€ 18,63
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Item No.: 973011631420
Type
Hose outer diameter10 mm
Connection threadR 1/4"
Pack size5 pieces
Part No.-
TypeKQ2VT10-02AP
€ 19,40
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 7-10 working days
Item No.: 973011631421
Type
Hose outer diameter10 mm
Connection threadR 3/8"
Pack size5 pieces
Part No.-
TypeKQ2VT10-03AP
€ 19,94
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 7-10 working days
Item No.: 973001163141
Type
Hose outer diameter10 mm
Connection threadR 1/2"
Pack size5 pieces
Part No.01163141
TypeKQ2VT10-04AP
€ 20,54
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 7-10 working days
Item No.: 973011631422
Type
Hose outer diameter12 mm
Connection threadR 1/4"
Pack size5 pieces
Part No.-
TypeKQ2VT12-02AP
€ 21,27
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 4 weeks
Item No.: 973011631423
Type
Hose outer diameter12 mm
Connection threadR 3/8"
Pack size5 pieces
Part No.-
TypeKQ2VT12-03AP
€ 21,39
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 10 weeks
Item No.: 973011631424
Type
Hose outer diameter12 mm
Connection threadR 1/2"
Pack size5 pieces
Part No.-
TypeKQ2VT12-04AP
€ 23,49
Price incl. VAT
plus € 29,00 shipping costs
Delivery time 3 weeks
Ratings


No evaluation has been given
