Product Description
- The pneumatically controlled AVA soft start valve is used in pneumatic control circuits where pressure release is to be triggered by an external pneumatic signal.
- They are particularly suitable for systems with decentralised or network-independent control.
- Typical industries include general mechanical engineering, automation technology and industrial production systems.
- The AVA soft start valve has a pneumatically controlled 3/2-way valve with an integrated check valve.
- The valve housing is made of corrosion-protected die-cast aluminium.
- Controlled pressurisation is achieved by means of an external control voltage via a pneumatic pilot connection.
- Material Valve body, top and bottom covers – die-cast aluminium
- Material Piston, needle valve and sealing plug – POM, NBR
- Medium - Compressed air
- Ambient and medium temperature - 0 to 60°C (To prevent freezing at low temperatures, the product should be operated with dry compressed air.)
- Test pressure - 1.5 MPa
- Operating pressure range - 0.2 to 1.0 MPa
- Flow rate – 3269 to 11908 l/min
- Pressure gauge connection size - 1/8"
- Connection thread - G 3/8" to 1"
- Protection class - IP65
- Width - 66 to 128 mm
- Depth - 40 to 74 mm
- Height (without silencer) – 112.6 to 137.6 mm
- Weight - 450 to 1320 g
