Vacuum Pump - Air - Connection 1/8"- Pumping Speed 1 l/min - Ejector Principle

(Exemplary presentation)
Item No.:
175801000129
Product Description
  • The vacuum ejector is ideal for extracting filtered, lubricated or unlubricated compressed air using a vacuum.
Description
  • The housing is made of anodised aluminium, the nozzles of brass.
  • The compact single-stage ejector creates a vacuum by flowing compressed air through a special ejector nozzle.
  • The 14% lower air consumption compared to equivalent single-stage ejectors is an outstanding feature.
  • The ejector has no wearing parts and can be mounted directly using suction cups.
  • To prevent the moving parts from freezing, the compressed air must be free of moisture below +2 °C.
Technical Data
  • Housing material - anodised aluminium
  • Nozzle material - brass
  • Dimensions (WxDxH) - 42 x 20 x 25 mm
  • Suction capacity - 28 nl/min.
  • max. vacuum - 0.85 bar
  • Operating pressure - 5 (optimum) to max. 8 bar
  • Air consumption - approx. 42 nl/min. at 5 bar
  • Connections - G ⅛ inch
  • Noise emission - 66 to 74 dB(A)
  • Operating temperature - -20 to +150 °C
  • Weight - 0.054 kg
