Throttle check valve AS002FS – PBT/brass – hose outer diameter 4 to 12 mm – with numerical display – price per piece
| From € 25,21 |
| Price incl. VAT |
| plus € 29,00 shipping costs |
Do you have any questions?
We would like to assist you!
We would like to assist you!
Product Description
- The AS*2F-A throttle check valve is used for precise air volume regulation in pneumatic control systems, e.g. in blow air applications.
- It is suitable for installation in control panels with an optional switch panel adapter and is compatible with polyamide, soft polyamide, polyurethane and fluoropolymer hoses.
- The AS*2FS throttle check valve has a plug connection on both sides, an enlarged, smooth-running adjustment knob for precise fine adjustment and a digital display.
- The metal parts are made of brass.
- Its compact design makes it approx. 27% lighter than previous models.
- The design with chemically nickel-plated brass parts ensures high flow reproducibility and mechanical stability.
- Several throttle check valves can be easily grouped together and fastened together.
- The valve also has four mounting options: direct, bracket, L-mounting element, DIN rail and a type plate for attaching an identification label.
- Valve body material – PBT / brass
- Material adjustment knob – POM
- Needle material – PBT
- Needle guide material – brass
- Seal material, O-ring – NBR
- Material display gear - POM
- Medium – compressed air
- Ambient and media temperature - -5 to 60°C (no freezing)
- Test pressure – 1.5 MPa
- max. operating pressure - 1.0 MPa
- max. operating pressure - 0.1 MPa
- suitable hose material – polyamide, soft polyamide, polyurethane, FEP, PFA
- Adjustment knob diameter – 9.4 to 18.8 mm
- Height – 33.9 to 64.3 mm
- Length - 37.6 to 81.3 mm
- Width - 13.6 to 26 mm
- Weight - 5.5 to 47.9 g
- Price per unit
Versions: (11)
| Article No. | Hose outer diameter | Part no. | Type | Price incl. VAT | |||||
|---|---|---|---|---|---|---|---|---|---|
|
202801489267 | 4 mm | 01489267 | AS1002FS-04 |
|
||||
|
|||||||||
|
202801489268 | 6 mm | 01489268 | AS1002FS-06 |
|
||||
|
|||||||||
|
202801489269 | 4 mm | 01489143 | AS2002FS-04 |
|
||||
|
|||||||||
|
202801489270 | 6 mm | 01489146 | AS2002FS-06 |
|
||||
|
|||||||||
|
202801489271 | 6 mm | 01492501 | AS2052FS-06 |
|
||||
|
|||||||||
|
202801489272 | 8 mm | 01489537 | AS2052FS-08 |
|
||||
|
|||||||||
|
202801489273 | 6 mm | 01505154 | AS3002FS-06 |
|
||||
|
|||||||||
|
202801489274 | 8 mm | 01489720 | AS3002FS-08 |
|
||||
|
|||||||||
|
202801489275 | 10 mm | 01489721 | AS3002FS-10 |
|
||||
|
|||||||||
|
202801489276 | 10 mm | 01490542 | AS4002FS-10 |
|
||||
|
|||||||||
|
202801489277 | 12 mm | 01489241 | AS4002FS-12 |
|
||||
|
|||||||||
